Description

ArmaSound Supersilence Ductliner is an advanced acoustic insulation material specifically engineered for effective airborne sound absorption, damping, and barrier properties within ducting systems. Crafted from an open-cell elastomeric foam based on synthetic rubber, this ductliner is a superior solution for creating quieter environments in commercial, residential, and industrial buildings. Gitco-sa.com, as an authorized Armacell distributor in Saudi Arabia and Bahrain, provides access to this high-performance product. A key benefit of ArmaSound Supersilence Ductliner is its fiber-free composition, which contributes to better indoor air quality by preventing airborne fibers. It also features built-in Microban® antimicrobial protection, inhibiting bacterial and fungal growth, ensuring a hygienic and durable installation. The ductliner exhibits excellent thermal conductivity, with $\lambda_d \le 0.045 \text{ W/(m·K)}$ at 0°C, adding thermal insulation benefits. It is highly resistant to erosion, cracking, or delamination even at high air velocities (up to 10,000 fpm, ASTM C1071), making it robust for duct applications. The product boasts impressive sound absorption coefficients (αw and NRC), with performance varying by thickness: a 50mm thickness achieves a Weighted Sound Absorption Coefficient (αw​) of 1.0 (Class A) and an NRC of 1.05, demonstrating its “super silent” capabilities. It operates effectively from -20°C to 85°C (0°C for self-adhesive versions) and offers practical fire behavior as a self-extinguishing material that does not drip or spread flames.

Key Features of ArmaSound Supersilence Ductliner:

• Exceptional Acoustic Performance: Achieves up to 1.0 (Class A) and NRC up to 1.05 for superior sound absorption across a broad frequency range.
• Fiber-Free: Promotes better indoor air quality, ideal for sensitive environments.
• Microbe Resistant: Contains in-built Microban® antimicrobial protection to prevent bacterial and fungal growth.
• Excellent Erosion Resistance: Withstands high air velocities without degradation.
• Damping and Barrier Properties: Reduces noise transmission and vibration effectively.
• Thermal Insulation: Provides additional thermal benefits ($\lambda_d \le 0.045 \text{ W/(m·K)}$ at 0°C).
• Practical Fire Behavior: Self-extinguishing, does not drip or spread flames.
• Easy to Apply: Simplifies installation in ducting systems.
• Wide Service Temperature Range: Effective from -20°C (or 0°C for self-adhesive) to 85°C.

Product Variations of ArmaSound Supersilence Ductliner:

ArmaSound Supersilence Ductliner is available in a range of thicknesses, each offering enhanced acoustic performance:

• 6mm thickness: αw​=0.2 (Class E), NRC = 0.2
• 10mm thickness: αw​=0.25 (Class E), NRC = 0.35
• 15mm thickness: αw​=0.35 (Class D), NRC = 0.55
• 20mm thickness: αw​=0.4 (Class D), NRC = 0.60
• 25mm thickness: αw​=0.55 (Class D), NRC = 0.80
• 30mm thickness: αw​=0.65 (Class C), NRC = 0.85
• 40mm thickness: αw​=0.8 (Class B), NRC = 0.85
• 50mm thickness: αw​=1.0 (Class A), NRC = 1.05Know more about ArmaSound SuperSilence Ductliner:
  1. What is ArmaSound SuperSilence Ductliner?
     ArmaSound SuperSilence Ductliner is a fiber-free, open-cell elastomeric foam acoustic insulation material, based on synthetic rubber, from Armacell. It’s designed to significantly reduce noise in HVAC ducts, air handling units, and plant rooms.
  2. What are the primary functions of ArmaSound SuperSilence Ductliner?
     Its main functions are:
     • High acoustic absorption: Effectively reduces airborne noise across a broad frequency range.
     • Noise dampening and barrier properties: Minimizes duct and plant room noise.
     • Improved Indoor Air Quality (IAQ): Being fiber-free and incorporating antimicrobial protection.
  3. Does ArmaSound SuperSilence Ductliner contain fibers?
     No, a key feature is that it is fiber-free and non-particulating, meaning it does not release fibers into the airstream, which is crucial for maintaining good indoor air quality.
  4. What is Microban® technology in ArmaSound SuperSilence Ductliner?
     Microban® is an active antimicrobial product protection built into the material during manufacturing. It helps prevent the growth of bacteria, fungi, mold, and mildew for the lifetime of the product, contributing to healthier indoor air quality.
  5. What is the fire performance rating of ArmaSound SuperSilence Ductliner?
     It demonstrates excellent fire performance, being self-extinguishing, not dripping, and not spreading flames. It typically achieves Class 1 for surface spread of flames (BS 476 Part 7) and HB, V-0 for flammability (UL 94).
  6. What is the Noise Reduction Coefficient (NRC) and Weighted Sound Absorption Coefficient (αw​) for ArmaSound SuperSilence Ductliner?
     The NRC and αw​ values vary by thickness:
     • For 25mm thickness, NRC is typically 0.70, and αw​ is 0.50 (Class D).
     • For 50mm thickness, NRC is typically 0.90, and αw​ is 0.90 (Class A). This demonstrates its high noise absorption.
  7. What are the typical thicknesses available for ArmaSound SuperSilence Ductliner?
     It is available in sheets with various thicknesses, commonly 6 mm, 10 mm, 15 mm, 20 mm, 25 mm, 30 mm, 40 mm, and 50 mm.
  8. Is ArmaSound SuperSilence Ductliner easy to install?
     Yes, it is designed for quick and easy installation. It does not require bitumen, tissue paper, or perforated sheets for application. It’s often available in self-adhesive sheets for simplified installation.
  9. What are the common applications for ArmaSound SuperSilence Ductliner?
     It is ideal for acoustic insulation in:
     • HVAC ducts
     • Air handling systems
     • Plant rooms
     • Architectural acoustics
     • Commercial buildings, public buildings, hotels, hospitals, schools, and clean room applications.
  10. Does it have high air erosion resistance?
      Yes, it boasts high air erosion resistance – up to 10,000 fpm (feet per minute), meaning it resists erosion, cracking, or delamination even at high air velocities inside ducts.
  11. What is the density of ArmaSound SuperSilence Ductliner?
      Its density is typically in the range of 140 to 180 Kg/m³. This density helps dampen duct rattling and vibration.
  12. Does ArmaSound SuperSilence Ductliner also provide thermal insulation?
      While primarily an acoustic product, as an elastomeric foam, it does possess thermal insulation properties. Its declared thermal conductivity (λd​) is $\le 0.047 \text{ W/(m·K)}$ at $20\text{ °C}$, contributing to energy efficiency.
  13. What is the service temperature range for ArmaSound SuperSilence Ductliner?
      The maximum service temperature is $+85\text{ °C}$, and the minimum service temperature is $-20\text{ °C}$ (for self-adhesive sheets, minimum is $0\text{ °C}$).
  14. Is it resistant to moisture and microbial growth?
      Yes, its hydrophobic (water-resistant) properties and built-in Microban® antimicrobial protection ensure resistance against microbial growth (no bacterial growth, no fungal growth visible) and help maintain its effective performance for its useful lifetime.
  15. What certifications does ArmaSound SuperSilence Ductliner hold?
      It is tested according to various international standards, including EN ISO 354, EN ISO 11654 for acoustics, BS 476 Part 7, UL94 for fire performance, and EN ISO 846 for antimicrobial behavior. Microban is also EPA and USFDA approved.
  16. How does ArmaSound SuperSilence Ductliner improve Indoor Air Quality (IAQ)?
      By being fiber-free, dust-free, formaldehyde-free, non-particulating, and incorporating active antimicrobial protection, it significantly reduces the potential for microbial growth and particle release into the airstream, thereby enhancing IAQ.
  17. Can ArmaSound SuperSilence Ductliner be used in cleanroom applications?
      Yes, its hygienic properties, including antimicrobial protection and being fiber-free, make it specially recommended for applications requiring high cleanliness standards, such as hospitals and cleanroom applications.
  18. What is the standard sheet size for ArmaSound SuperSilence Ductliner?
      The standard sheet size is typically 1 m x 1 m.
  19. Where can one purchase ArmaSound SuperSilence Ductliner in Bahrain and Saudi Arabia?
      Gitco-sa.com, as an authorized distributor and partner of Armacell in Saudi Arabia and Bahrain, would be a primary supplier for ArmaSound SuperSilence Ductliner. They would carry this product as part of their comprehensive Armacell acoustic insulation range.
  20. Why choose a specialized supplier like Gitco-sa.com for ArmaSound SuperSilence Ductliner in Bahrain/Saudi Arabia?
      Choosing a specialist like Gitco-sa.com ensures access to genuine Armacell products with verified technical data. They offer technical guidance on product selection and application, ensuring the solution meets specific project acoustic requirements and complies with relevant building codes in the region. Their local presence provides reliable supply, technical support, and potentially installation guidance.

The density also varies, available in the range of 140 to 180 Kg/m³. The ductliner may also be available in self-adhesive formats for quicker installation, which impacts the minimum service temperature to 0°C. For specific dimensions and options, please contact Gitco-sa.com.
